Simple polarizing microscope MP20

The polarizing microscope MP20 is a teaching-level instrument that uses the polarization characteristics of light to study and identify birefringent substances. It has a wide range of uses.

Share:

Get Exclusive Offers and Updates!

    Description

    MP20 Polarizing Microscope is a kind of essential instrument for studying and identifying the materials with double refraction characteristics, by using polarizing feature. This microscope is widely used in many fields, such as observation of crystalline inclusions, muscle tissue, nerve tissue, plant fiber and other structural details of the teeth, bone, and living cells, as well as analysis of drug composition and properties. Furthermore, in the field of inorganic chemistry, the fine structure of crystallization conditions of various kinds of salts which cannot be seen in natural light can be observation through polarizing microscope



    Feature

    Clear image:

    Equipped with wide-field eyepieces and achromatic objectives, the field of view is large and clear.

    Coarse and fine focusing, limit locking:

    Coaxial coarse and fine motion focusing mechanism, adjustable coarse and tight motion, with limit locking device.

    Halogen transillumination, adjustable brightness:

    Halogen lamp transmitted lighting, brightness adjustable.

    Sample images:

    Specifications

    Model MP20
    Eyepiece Wide field WF10X(Φ18mm)
    Objective Achromatic objective 4X/0.10
    Achromatic objective 10X/0.25
    Achromatic objective 40X/0.65 (Spring)
    Achromatic objective 100X/1.25(Spring, oil)
    Observation tube Binocular, inclined 30°
    Analyzer Sliding
    Focus system Coaxial coarse/fine focus system, with tension adjustable and limit stopper,minimum graduation in fine movement is 2μm
    Nosepiece Quadruple (Backward ball bearing inner locating)
    Stage Rotatable stage (Diameter:Φ120mm)
    Abbe condenser NA.1.25 Rack & pinion vertical adjustable
    Filter Blue filter
    Frosted glass
    Polarizer 360° rotatable
    Analyzer Push-pull
    Illumination unit 6V 20w, halogen bulb, brightness adjustable
